| Place of Origin: | China |
|---|---|
| Brand Name: | Local Brand |
| Certification: | ISO9001 |
| Model Number: | Filter Material Roll |
| Minimum Order Quantity: | 1000kg |
| Price: | Negotiable |
| Packaging Details: | carton and pallet |
| Delivery Time: | 4~6 weeks |
| Supply Ability: | 15000kgs per month |
| Basis Weight: | 86g/m2 | Overall Caliper: | 0.51mm |
|---|---|---|---|
| Air Permeability: | 115L/m2/s | Max Pore: | 23 Micron |
| DOP Penetration: | 9% | TENSILE STRENGTH - MD: | 2.8kN/m |
| TENSILE STRENGTH - CD: | 1.5kN/m | ||
| High Light: | 86g/M2 Filter Media Paper,Ultralight Filter Media Paper,Separator Filter Paper Roll |
||
Filter Paper Filter Material Roll Used For Oil Gas Separator
Description
The coalescing process involves agglomerating individual molecules to form larger droplets, which are then separated from the media through gravity. Coalescer filters remove submicronic water, oil, and solid contaminants from process streams. The most common use for fluids is to remove water from oil or vice versa. The most common use for gases is to remove liquid or solid particles from the gas.
Benefits of Coalescer Filter Media
Companies and organizations use our coalescer filtration systems due to their impressive features and benefits, which include:
Broad surface area, which leads to lower pressure drops
Keeping contaminants from affecting downstream equipment
98% micron rating for efficiency
Removing a maximum quantity of liquid and solid particulates from gas process streams
Long lifespan
Low maintenance and operational costs
Excellent solids holding
High-capacity flow rates
What Are Some Common Applications of Coalescer Filter Media?
Applications of coalescer filter media typically involve the separation of hydrocarbon compounds—like oil—from water. Other applications include:
Removing liquid and solid particulates from airstreams and hydrocarbon products during processing and refining
Filtering aircraft fuel
Compressing natural gas
Removing oil from water
Removing liquids from hydrocarbons
Separating oil in refrigerants
Filtering process streams in refineries and petrochemical plants
Producing fertilizers
Filtering industrial steam
Transportation
