| Place of Origin: | China |
|---|---|
| Brand Name: | Comfort |
| Model Number: | Separator Filter |
| Minimum Order Quantity: | Negotiable |
| Packaging Details: | 100000pcs |
| Delivery Time: | 5-8 working days |
| Payment Terms: | L/C, T/T |
| Structure Type: | Separator Box Filter | Filter Medium: | Fiberglass |
|---|---|---|---|
| Efficiency: | M6/F8/H13/H14 | Temperature Resistance: | 150℃/250℃/300℃/350℃ |
| Recommended Final Pressure: | 500 Pa | HS Code: | 8421999000 |
| High Light: | 500Pa Separator Filter Element,Heatproof Separator Filter Element,Non Corroding Pleated HEPA filter |
||
High-Temperature Resistant Separator HEPA Filter
Description:
We produce all kinds of different normal size High-temperature resistant Separator HEPA Filters.
We have also the ability to manufacture according to customized size and material specifications.
| Model Dimensions (W×H×D) mm |
Filter grade EN 779/EN1822 |
Airflow / pressure drop m³/h / Pa (± 15%) |
Area m2 |
Unit volume m³ |
|---|---|---|---|---|
| 305x610x292 |
M6 |
1700/100 | 6.69 | 0.054 |
| 610x610x292 | M6 | 3400/100 | 13.66 | 0.108 |
| 305x610x292 | F8 | 1700/135 | 6.69 | 0.054 |
| 610x610x292 | F8 | 3400/135 | 13.66 | 0.108 |
| 305x610x150 | H13 | 500/220 | 3.20 | 0.028 |
| 610x610x150 | H13 | 1000/220 | 6.40 | 0.056 |
| 915x610x150 | H13 | 1500/220 | 9.60 | 0.084 |
| 305x610x292 | H13 | 1250/220 | 6.69 | 0.054 |
| 610x610x292 | H13 | 2500/220 | 13.66 | 0.108 |
| 305x610x150 | H14 | 500/220 | 3.20 | 0.028 |
| 610x610x150 | H14 | 1000/220 | 6.40 | 0.056 |
| 915x610x150 | H14 | 1500/220 | 9.60 | 0.084 |
| 305x610x292 | H14 | 1250/220 | 6.69 | 0.054 |
| 610x610x292 | H14 | 2500/220 | 13.66 | 0.108 |
Materials:
| Frame | Galvanized steel sheet, 304 Stainless steel sheet |
| Separator | Aluminum foil |
| Media | Glass Fiber |
| Gasket | High-temperature resistant silicone sponge |
| Sealant | Polyurethane |
| Face Guard | Stainless steel sheet |
Applications:
Features:
Detailed Pictures:
